Advanced Surgical Drill kit (Easy Fast S) Blue Box
0,00 €
Advanced Surgical Drill Kit Screw Drivers Torque Ratchet Wrench
Autoclave Box CE
This set includes:
Torque Ratchet 10-40 NCM
4.0mm Square Handle
Hand Wheels
Pilot 2.0(White)
Regular Drills
Reamers
Note: The use of instrument combination is assigned by giving different color schemes.
| Regular Drills | Color Indication | Actual Reamer Size | Color Indication | For Implant |
| 2.5mm | Pink | 2.6mm | Purple | 3.0mm |
| 2.9mm | Green | 3.1mm | Green | 3.5mm |
| 3.2mm | Yellow | 3.4mm | Yellow | 3.8mm |
| 3.5mm | Red | 3.9mm | Red | 4.3mm |
| 4.4mm | Blue | 4.6mm | Blue | 5.0mm |
For 3.0mm Implant, use pilot drill of 2.0mm (White) then regular drill of 2.5mm (Pink) and reamer of 2.6mm (Purple)
For 3.5mm Implant, use pilot drill of 2.0mm (White) then regular drill of 2.9mm (Green) and reamer of 3.1mm (Green)
For 3.8mm Implant, use pilot drill of 2.0mm (White) then regular drill of 2.9mm (Green), 3.2mm (Yellow) and reamer of 3.4mm (Yellow)
For 4.3mm Implant, use pilot drill of 2.0mm (White) then regular drill of 2.9mm (Green), 3.2mm (Yellow) 3.5mm (Red) and reamer of 3.9mm (Red)
For 5.0mm Implant, use pilot drill of 2.0mm (White) then regular drill of 2.9mm (Green), 3.2mm (Yellow), 3.5mm (Red), 4.4mm (Blue) and reamer of 4.6mm (Blue)
| Driver Size | Used by |
| 1.3mm (Length of Small 10mm & Large 25mm) | 4.0mm Torque Ratchet Wrench |
| 1.3mm (Length of Medium is 15mm) | Hand Driver |
| 1.3mm (Length of Small is 10mm) | Handpiece |
| Driver Size | Used by |
| 2.0mm (Length of Small is 7mm & Medium 17mm) | 4.0mm Torque Ratchet Wrench |
| 2.0mm (Length of Large is 20mm) | Handpiece |
| Driver Size | Used by |
| 2.4mm (Length of Small is 7mm & Medium 17mm) | 4.0mm Torque Ratchet Wrench |
| 2.4mm (Length of Small is 10mm & Large 20mm) | Handpiece |
INSTRUMENTS MATERIAL:
FRENCH STAINLESS STEEL
AUTOCLAVABLE BOX 135 DEGREE CENTIGRADE
